All-new design allows for access to every connector and fuse from the top of the box
WeCanX™, our newest CAN-based communication system provides true system synchronization, greater speed capabilities, expanded peripheral add-ons, and full support of diagnostics
Vehicle-to-Vehicle Sync automatically synchronized lights and tones on multiple vehicles
Dynamic Variable Intensity™ patterns gradually increase or decrease the output intensity for nighttime emergency scenes
Advanced Customization with support of 99 WeCanX devices, allowing you to customize Core in ways never before possible in a control system
Supports remote firmware updates via USB-C with Whelen Command®, our newest programming software
Software
Whelen Command®
Hardware
Up to 99 WeCanX devices
Outputs
2 15A outputs
4 10A outputs
16 2A outputs
1 dry contact relay
23 total outputs
Flashing outputs
Every output across the system can be synchronized
Inputs
12 logic inputs
1 ignition power-up input
4 analog inputs
17 total inputs
Connections
1 ethernet connection
1 WeCanX connection
2 CANport™
1 USB-A host
1 USB-C
1 Micro SD card slot
99 remote modules
Sensors
Battery voltage sensor
Temperature sensor
DVI
Gradually increase or decrease the output intensity within a flash pattern or tone
Tone Sync
Sync amplifiers and speakers together
Sync tones with lights (Patent-Pending)
Diagnostics
Has diagnostic indicator
Expansion Modules
Lightbars, Inner Edge™ FST™ and RST™, External Amplifier, External Howler Siren, Remote 8 or 16 Output Expansion Module, Control Point and Input Expansion Module, Traffic Advisor™ Module, V2V Sync Module
Certifications
Meets all applicable SAE and California Title XIII requirements with various Whelen speakers
